The VLSI Blueprint: The Complete ASIC Design Flow
In the domain of integrated circuits, ASICs (Application-Specific Integrated Circuits) play a crucial role in powering a various array of electronic devices. Understanding the ASIC design flow is paramount for engineers and enthusiasts. This blog aims to provide an in- depth overview of the ASIC design process, from concept to fabrication for delivering next-generation products and cutting-edge embedded engineering solutions.
Overview of the ASIC design flow process
The ASIC design flow is a structured process for generating custom integrated circuits. It starts with customer requirement analysis, defining the chip's different functionality and specifications. Designers then design the top-level architecture, followed by RTL(Register Transfer Level) design to describe the circuit's behavior. Functional verification ensures the design meets customer requirements, while synthesis converts it into a gate-level netlist. Design for testability and physical design prepare the custom chip for manufacturing. Timing analysis and design rules validate its performance and manufacturing rules. Mask generation and tapeout send the design for fabrication. Post-tapeout validation tests the fabricated ASICs, and product integration integrates them into the final chip.
ASIC vs FPGA
ASICs (Application-Specific Integrated Circuits) and FPGAs (Field-Programmable Gate Arrays) are different types of integrated circuits. ASICs are custom-designed for particular tasks, offering quite high performance and power efficiency however with high development costs and long lead times. FPGAs are programmable, qualify for flexible reconfiguration after manufacturing, perfect for prototyping and low-to-medium volume production. They offer quick development cycles but have higher power consumption and lower performance compared to ASICs. ASICs are preferable for high-volume applications where optimization is critical, while FPGAs are excellent in applications requiring flexibility and quick time-to-market. Both have their unique pros and cons depending on the application's requirements.
ASIC design flow - in detail
ASIC design flow starts with customer specification.Where customer provides the number of specification of the chip typically the requirement which customer wants to develop in a chip. The entire design process passes through various design cycles.The ASIC design flow mainly divided in two parts:
Front-end design
ASIC front-end design also known as the RTL(Register Transfer Level) design. It involves the initial stages of creating custom integrated circuits, Including specification, architecture design, and RTL coding.
It starts with engineers collecting the requirements and defining the chip's functionality, converting them into a high-level architectural design. Register Transfer Level (RTL) coding follows, where RTL engineers describe the circuit's behavior using hardware description languages (HDL) like Verilog or VHDL. Functional verification makes sure the design meets specifications, while synthesis converts RTL code into gate-level netlists. Front-end design defining the chip's logic and functionality, sets the base for following physical design and fabrication stages.
Back-end design
ASIC back-end design is split into two parts i.e. Logic Design and Physical Design. It contains the crucial stages following front-end design, which mainly focus on translating logical designs into physical layouts ready for fabrication. It implies complex processes to optimize performance, minimize area, and ensure manufacturability.
Physical design includes floorplanning, where the chip's components are placed to optimize performance and minimize signal delays. Placement determines specific locations for logic cells, memory elements, and other components, while routing interconnects them to establish electrical connections. These tasks are followed by timing constraints and power considerations, to make sure that the design meets performance targets and power requirements.
The timing analysis ensures that signals travel through the chip within specified timing constraints, crucial for checking reliable operation. Design rule checks(DRC) validate the layout against factory-specific manufacturing rules, ensuring compliance with spacing, width, and other physical parameters.
Once the design process passes these all checks, mask generation will put the final design data in GDSII (Graphic Data Stream) format, ready for semiconductor fabrication. Tapeout, the final step, involves sending the design to the factory for manufacturing.
Back-end design plays a crucial role in ensuring the physical implementation of the ASIC aligns with the original specifications, for successful production. It needs expertise in physical design, timing analysis, and manufacturability considerations to deliver a high-quality, manufacturable chip.
ASIC design flow includes the requirement analysis, architectural design, RTL coding, synthesis, physical design, verification, and fabrication preparation. It makes sure custom integrated circuits are designed, validated, and ready for production as per customer requirement. Every stage is vital for meeting performance, power, and area requirements of the target application.
As technology progresses, the need for streamlined and refined ASIC design processes strengthens the possibilities for enterprises. Here at ACL digital, we recognize the significance of maintaining a leading edge in this ever-changing terrain. Our experienced team is dedicated to providing innovative solutions that surpass conventional standards. Contact us today to explore our Embedded offerings further and discover how we can assist you in realizing success not only in ASIC design but also in broader endeavors.
